In the "fire zone" of jet engines or gas turbines, piping is the most vulnerable link. Key pain points for aerospace engineers and maintenance, repair, and overhaul (MRO) specialists include:
Wall thickness eccentricity: Differences in concentricity create "thin spots" in the pipe wall. Under high-pressure thermal cycling (up to 800°C), these thin spots can become the starting point for pipe rupture, leading to catastrophic bursts.
Alternative risks: Using "commercial-grade" nickel alloys lacking the VIM+ESR dual vacuum refining process required for flight safety components.
At Gnee Alloy, we offer zero-leakage piping. Our GH3030 piping is specifically designed to maintain structural integrity in the most demanding aerospace environments.
Click to get a GH3030 product quote
High-temperature seamless tubing for GH3030 turbocharged engine
High-temperature seamless tubing for GH3030 turbocharged engine
GH3030 seamless steel pipe is a solution-strengthened 80Ni/20Cr high-temperature alloy. It is ideally suited for turbocharged engine environments, exhibiting excellent oxidation resistance and thermal fatigue resistance, with a temperature range of 800°C to 1100°C. It is an ideal choice for high-temperature combustor components, exhaust pipes, and thermocouple housings.
What are the components of GH3030?
GH3030 is a solid solution strengthened high-temperature alloy, mainly composed of nickel (Ni) and chromium (Cr), with a simple chemical composition. Its typical ratio is 80% nickel and 20% chromium.
1. GH3030 Global Standard Equivalence
| Parameter | Details |
|---|---|
| Designation | GH3030 / UNS N06075 / NiCr20Ti |
| Aviation Specifications | Fully compliant with AMS 5589 Equivalent and GB/T 15062 |
| Purity Process | Refined via VIM + ESR (Vacuum Induction Melting + Electroslag Remelting) |
2. Chemical composition of GH3030 seamless steel pipe (wt%)
| Element | Content (%) | Function |
|---|---|---|
| Nickel (Ni) | Balance (≥ 75.0) | Matrix element; high-temperature stability |
| Chromium (Cr) | 19.0 – 22.0 | Oxidation and corrosion resistance |
| Iron (Fe) | ≤ 1.5 | Strictly controlled to maintain nickel-base characteristics |
| Titanium (Ti) | 0.15 – 0.35 | Supplementary solid-solution strengthening; carbide stabilizer |
| Aluminum (Al) | ≤ 0.15 | Strictly controlled to prevent harmful phase formation |
| Carbon (C) | ≤ 0.12 | Low carbon for good weldability and toughness |
| Manganese (Mn) | ≤ 0.70 | Deoxidizer |
| Silicon (Si) | ≤ 0.80 | Deoxidizer |
| Phosphorus (P) | ≤ 0.030 | Ensures toughness |
| Sulfur (S) | ≤ 0.020 | Ensures hot workability |
| Copper (Cu) | ≤ 0.20 | Residual element |
2. Mechanical properties of GH3030 seamless steel pipe at high temperature
| Property | Value at 20°C (Room) | Value at 800°C (1472°F) | Industrial Advantage |
| Tensile Strength (σb) | ≥ 590 MPa | ≥ 140 MPa | Elite pressure containment. |
| Yield Strength (σp0.2) | ≥ 245 MPa | ≥ 100 MPa | Resists distortion at peak heat. |
| Elongation (δ5) | ≥ 35% | ≥ 50% | High plasticity for complex bending. |
3. Gnee Alloy GH3030 Quality Guaranteed
As a Reliable Supplier, we understand that in aerospace, there is no "margin for error."
✅️100% NDT Testing: Every meter of tubing undergoes Ultrasonic Testing (UT) and Eddy Current Testing (ET) to ensure zero internal voids.
✅️Hydrostatic Verification: Every batch is tested to its peak rated pressure to ensure Zero-Leakage performance.
✅️MTC 3.1 Traceability: Full heat analysis and mechanical test reports included with every shipment, ensuring total Global Compliance.
Gnee alloy GH3030 certificate
4. Applications of GH3030 alloy in aerospace and energy fields
Our Heavy-Duty GH3030 pipes power the world's most critical systems:
Turbine Engine Fuel Lines: Ensuring scale-free fuel delivery to injectors.
Aerospace Sensors: Protective sleeves for high-temp pressure and flow probes.
Exhaust Manifolds: Resisting thermal fatigue and oxidation.
Heat Exchangers: Specialized tubing for high-purity chemical heat transfer.
Contact us now to get the latest export price for GH4169 in 2026
FAQ
Q1: Is GH3030 technically identical to Nimonic 75 for turbine service?
A: Yes. GH3030 is the technical designation used in international blueprints for the same metallurgical system as Nimonic 75 / Alloy 75. It is globally interchangeable and meets all 800°C oxidation requirements.
Q2: How do you protect the internal diameter during shipping?
A: All our Bright Annealed (BA) tubes are capped with specialized plastic plugs and packed in reinforced, waterproof wooden crates to ensure the Mirror ID remains contaminant-free until installation.
Q3: Can you produce precision capillary tubes in GH3030?
A: Absolutely. We offer precision cold-drawing to achieve h8-h11 tolerances for small-diameter tubing (OD 1.0mm - 10mm) used in aerospace instrumentation.
Q4: Do you offer bulk discounts for aerospace maintenance programs (MRO)?
A: Yes. As a Tier-1 Manufacturer, we offer tiered Wholesale Pricing and dedicated inventory reserves for long-term contract partners.
