In high-temperature metallurgy, 800°C (1472°F) is often considered the "critical temperature." GH3030 (Nimonic 75 / XH78T) is a proven classic material within this temperature range, but what happens when your industrial applications require stable performance at 900°C or higher?
Are you currently troubled by heat deformation and creep failure: "Will my existing alloy lose its structural integrity as temperatures soar?" If your parts warp or thin at high temperatures, it's time to upgrade to a high-performance alloy. The transition from GH3030 to the tungsten-molybdenum-reinforced GH3044 is a fundamental way to extend component life.
Please request a price quote for GH3030 sheet metal
High-Temperature Performance Comparison of GH3030 and GH3044 Alloy Plates
High-Temperature Performance Comparison of GH3030 and GH3044 Alloy Plates
GH3030 and GH3044 alloy plates are high-temperature resistant nickel-based solid solution strengthened superalloy plates, commonly manufactured as plates, sheets, and strips, and widely used in aerospace and industrial fields. These materials are renowned for their high plasticity and stable performance under extreme temperature environments.
What are the components of GH3030?
GH3030 is a solid solution strengthened superalloy, primarily composed of nickel (Ni) and chromium (Cr), typically with 80% Ni and 20% Cr. This simple yet efficient alloy system provides excellent mechanical and chemical stability even under harsh conditions.
1.Comparison of chemical composition between GH3030 and GH3044 plates
| Element | GH3030 (Standard) | GH3044 (High Strength) | Key Role of GH3044 Additions |
| Nickel (Ni) | Balance (~80.0%) | Balance (~70-75%) | Matrix Stability |
| Chromium (Cr) | 19.0 - 22.0% | 23.5 - 26.5% | Enhanced Oxidation Barrier |
| Tungsten (W) | - | 13.0 - 16.0% | Extreme Heat Strengthening |
| Molybdenum (Mo) | - | ≤ 0.50% | Solid Solution Strength |
| Niobium (Nb) | - | 0.30 - 0.70% | Grain Refinement & Creep Strength |
2.Mechanical properties of GH3030 and GH3044 Sheet (at 20°C and 800°C)
| Property | GH3030 Plate | GH3044 Plate |
| Tensile Strength (20°C) | ≥ 735 MPa | ≥ 785 MPa |
| Yield Strength (20°C) | ≥ 245 MPa | ≥ 345 MPa |
| Elongation (δ5δ5) | ≥ 35% | ≥ 30% |
| Oxidation Rate (800°C) | Excellent | Superior (Near Zero Scaling) |
| Continuous Temp Limit | 800°C | 900°C - 1100°C |
Click to download the GH3030 alloy PDF file now
3. High-Temperature Performance Comparison of GH3030 Sheet and GH3044 Plate
GH3030: A Mainstay at 800°C
GH3030 is a simple, high-purity nickel-chromium alloy. Its 20% chromium content gives it excellent oxidation resistance. Furthermore, GH3030 is renowned for its high plasticity, making it the most cost-effective solution for complex furnace components and linings below 800°C.
GH3044: A High-Performance Expert Above 900°C
GH3044 is an alloy with significantly improved performance. It incorporates tungsten (W) and molybdenum (Mo) to enhance solid solution strengthening and niobium (Nb) to maintain carbide stability. This allows the alloy to maintain higher mechanical strength and creep resistance at temperatures of 900°C and above.
Download the GH3030 vs. GH3044 Technical Datasheet
4. How to Choose Between GH3030 and GH3044
When to Choose GH3030: When you need high plasticity for complex molding and a constant operating temperature below 800°C. It is the best choice for wholesale factory prices for liners and baffles.
When to Choose GH3044: When you find that parts are currently experiencing warping, surface thinning, or creep rupture at 800°C. GH3044 provides the high performance required for afterburners, gas turbine transition sections, and 1000°C industrial furnace supports.
Contact us now to get the latest export price for GH3030 in 2026
5. Why Choose Gnee Steel?
As your dedicated supply chain partner, Gnee Steel simplifies your material upgrade path:
VIM + ESR Precision Machining: Our GH3044 and GH3030 plates are manufactured using a double-melt refining process, ensuring zero defects in the internal structure of safety-critical components.
In Stock and Custom Sizes: We maintain a large inventory of plates in standard thicknesses (0.5-50mm) and offer precision waterjet cutting services, providing ready-to-use blanks.
Aerospace-Grade Certifications: Every shipment includes a complete material testing certificate (EN 10204 3.1), ensuring your projects meet international standards.
GH3030 Certificate
Check the inventory and wholesale price of GH3030 Plate
FAQ
Q1: Is GH3044 harder to weld than GH3030?
A: GH3044 is slightly more sensitive due to the high Tungsten (W) content. However, with proper TIG/MIG parameters, it maintains Excellent Weldability. We can provide a welding procedure guide upon request.
Q2: Will switching to GH3044 significantly increase my costs?
A: GH3044 is more expensive than GH3030 due to the Tungsten and Chromium content. However, for 900°C service, its Long Service Life makes it a more Cost-Effective Solution by reducing maintenance cycles by over 50%.
Q3: Can I get GH3044 in "Bright Annealed" (BA) finish?
A: Yes. We offer BA finishes for cold-rolled sheets (0.5-4.0mm) to ensure a mirror-like, oxide-free surface for your high-performance aerospace projects.
Q4: Do you offer MRO supply support for international clients?
A: Absolutely. We specialize in MRO Supply, maintaining the most common XH78T and GH3044 sizes for Global Shipping with fast 7-day lead times for stocked items.
