LR AH40 DH40 EH40 FH40 STEEL PLATES FOR SHIPBUILDING

GNEE Steel can supply LR shipbuilding steel plate/ marine steel plate, mainly used in construction for ships. Production Size: Thickness: 4mm- 200mm; Width: 1000mm- 4000mm; Length: 4000mm- 12000mm. Production ability:10000 Tons Per Month. Production Way: Hot Rolled Techanical Details: Heat Treatment: Normalized, Quenched, Tempered, Impact Test,.

GNEE Steel can supply LR shipbuilding steel plate/ marine steel plate, mainly used in construction for ships.

Production Size: Thickness: 4mm- 200mm; Width: 1000mm- 4000mm; Length: 4000mm- 12000mm.

Production ability:10000 Tons Per Month.

Production Way: Hot Rolled

Techanical Details:

Heat Treatment: Normalized, Quenched, Tempered, Impact Test,.

LR Grade AH40 Shipbuilding Steel Plate Chemical Composition and Mechanical Property

STEEL PLATES FOR SHIPBUILDING

C max	Si max	Mn	P max	S max	Als	Nb	V	Ti max.	Cu max.	Cr max.	Ni max.	Mo max.	N max.
0.18	0.50	0.90-1.60	0.030	0.030	0.015	0.02-0.05	0.05-0.10	0.02	0.35	0.20	0.40	0.08	-

Yield Strength (MPa) min.	Tensile Strength (MPa)	Elongation min. %
390	510-660	20

LR Grade DH40 Shipbuilding Steel Plate Chemical Composition and Mechanical Property

High Strength Steel Plate

C max	Si max	Mn	P max	S max	Als	Nb	V	Ti max.	Cu max.	Cr max.	Ni max.	Mo max.	N max.
0.18	0.50	0.90-1.60	0.025	0.025	0.015	0.02-0.05	0.05-0.10	0.02	0.35	0.20	0.40	0.08	-

Yield Strength (MPa) min.	Tensile Strength (MPa)	Elongation min. %
390	510-660	20

LR Grade EH40 Shipbuilding Steel Plate Chemical Composition and Mechanical Property

Hull Structure Steel Sheets

C max	Si max	Mn	P max	S max	Als	Nb	V	Ti max.	Cu max.	Cr max.	Ni max.	Mo max.	N max.
0.18	0.50	0.90-1.60	0.025	0.025	0.015	0.02-0.05	0.05-0.10	0.02	0.35	0.20	0.40	0.08	-

Yield Strength (MPa) min.	Tensile Strength (MPa)	Elongation min. %
390	510-660	20

LR Grade FH40 Shipbuilding Steel Plate Chemical Composition and Mechanical Property

Shipbuilding structure steel plate

C max	Si max	Mn	P max	S max	Als	Nb	V	Ti max.	Cu max.	Cr max.	Ni max.	Mo max.	N max.
0.16	0.50	0.90-1.60	0.020	0.0.20	0.015	0.02-0.05	0.05-0.10	0.02	0.35	0.20	0.80	0.08	0.009

Yield Strength (MPa) min.	Tensile Strength (MPa)	Elongation min. %
390	510-660	20
