KR high-strength hull structure steel is divided into strength grades according to its minimum yield strength, and each strength grade is divided into A, D, E, and F 4 grades according to its impact toughness.
A, D, E, and F respectively represent the impact toughness that they can achieve at 0°, -20°, -40°, and -60° respectively.
KR A56 D56 E56 F56 ship plate flaw detection requirements:
first detection, second detection, third detection.
KR A56 D56 E56 F56 shipbuilding steel plate density:
7.85/m3.
KR A56 D56 E56 F56 ship plate weight adjustment formula:
thickness * width * length * density.
KR A56 D56 E56 F56 marine grade steel plate regular size:
8-80mm*2000-2500mm*8000-10000mm
KR Grade A56 Shipbuilding Steel Plate Chemical Composition and Mechanical Property
| C max | Si max | Mn | P max | S max | N max. |
|
0.21 |
0.55 | 1.70 |
0.030 |
0.030 |
0.020 |
| Yield Strength (MPa) min. | Tensile Strength (MPa) | Elongation min. % |
| 550 | 670-830 | 16 |
KR Grade D56 Shipbuilding Steel Plate Chemical Composition and Mechanical Property
| C max | Si max | Mn | P max | S max | N max. |
|
0.20 |
0.55 | 1.70 |
0.025 |
0.025 |
0.020 |
| Yield Strength (MPa) min. | Tensile Strength (MPa) | Elongation min. % |
| 550 | 670-830 | 16 |
KR Grade E56 Shipbuilding Steel Plate Chemical Composition and Mechanical Property
| C max | Si max | Mn | P max | S max | N max. |
|
0.20 |
0.55 | 1.70 |
0.025 |
0.025 |
0.020 |
| Yield Strength (MPa) min. | Tensile Strength (MPa) | Elongation min. % |
| 550 | 670-830 | 16 |
KR Grade F56 Shipbuilding Steel Plate Chemical Composition and Mechanical Property
| C max | Si max | Mn | P max | S max | N max. |
|
0.18 |
0.55 | 1.60 |
0.020 |
0.020 |
0.020 |
| Yield Strength (MPa) min. | Tensile Strength (MPa) | Elongation min. % |
| 550 | 670-830 | 16 |
