GNEE's Cold-Rolled Steel Coil Product Groups
GNEE supplies cold-rolled steel coils in four distinct product groups, each designed to meet specific manufacturing requirements:
- Cold-Rolled Low Carbon Steel: Ideal for applications requiring good formability and weldability, such as automotive panels and household appliances. This type of steel is known for its excellent ductility and smooth surface finish.
- Cold Harden Coil: These coils are processed to enhance their hardness and strength, making them suitable for applications that demand high durability and resistance to wear and tear.
- Phosphorus High Strength Steel: These coils are strengthened with the addition of phosphorus, making them suitable for high-strength applications where both strength and formability are required.
Application of Cold-rolled steel sheet
- OA product Printer
- Video
- Air conditioner
- Refrigerator
- Washing machine
- Communication machine cabinets
- Battery shell
- Vitreous enamelling
Grades of cold-rolled steel sheets that GNEE can supply：
1,Introduction of grades and uses of Cold-rolled steel sheet steel for drawing series
Material category |
Baosteel en erprise standards | Equivalent foreign standard | Description | ||
| Standard number | Grade | Standard number |
Grade | ||
| General use | Q/BQB402-2009 Q/BQB403-2009 Q/BQB408-2009 |
SPCC DC01 BLC |
EN10327 JISG3141 |
SPCC DC01 JSC270C |
Steel for general shaping and processingof refrigerator and other household applianceshell, oil drums, steel furniture |
| Used for drawing | Q/BQB402-2009 Q/BQB403-2009 Q/BQB408-2009 |
SPCD DC03 BLD |
EN10327 JISG3141 |
SPCD DC03 JSC270D |
Steel for the drawing and shaping of household appliances |
| Used for deep drawing | Q/BQB402-2009 Q/BQB403-2009 Q/BQB408-2009 |
SPCE DC04 BUSD |
EN10327 JISG3141 |
SPCE DC04 JSC270E |
Steel for deep drawing and shaping process |
| Used for special deep drawing |
Q/BQB402-2009 Q/BQB403-2009 Q/BQB408-2009 |
SPCF(SPCEN) | EN10327 JISG3141 |
SPCF DC05 JSC270F |
Steel for special deep drawing and shaping process |
| DC05 | |||||
| BUFD | |||||
| Extra deep drawing | Q/BQB402-2009 | SPCG DC06 BSUFD |
EN10327 JISG3141 |
SPCG DC06 JSC260G |
Steel for special deep drawing and shaping process |
| Q/BQB403-2009 | |||||
| Q/BQB408-2009 | |||||
| Used for special extra-deep drawing |
Q/BQB403-2009 | DC07 | EN10327 JISG3141 |
DC07 | Steel with particularly good deep drawing propertie |
2.Mechanical properties of Cold-rolled steel sheet drawing series
| Grade |
MPa Yield strength |
MPa Tensilestrength ≥ |
≥Elongation % A80mm | r90° | n90° | |||||
| Nominal tick ness(mm) | ≥ | |||||||||
| <0.30 | 0.30~<0.50 | 0.50~<0.70 | 0.70~<1.0 | 1.0~<1.6 | 21.6 | |||||
| DC01 | 140~280 | 270 | 24 | 26 | 28 | 30 | 32 | 34 | - | - |
| DC03 | 140~240 | 270 | - | 30 | 32 | 34 | 35 | 36 | 1.3 | - |
| DC04 | 130~210 | 270 | - | 34 | 36 | 38 | 39 | 40 | 1.6 | 0.18 |
| DC05 | 120~180 | 270 | - | 35 | 38 | 40 | 40 | 41 | 1.9 | 0.2 |
| DC06 | 110~170 | 260 | - | 37 | 39 | 41 | 42 | 43 | 2.1 | 0.22 |
| DC07 | 100~150 | 250 | - | 40 | 42 | 44 | 2.5 | 0.23 | ||
| Grade | MPa Yield strength |
MPa Tensile strength ≥ |
≥Elongation%(LO=50mm,b=25mm) | rm | |||||||
| Nominal thickness(mm) | (mm) Nominal thickness |
||||||||||
| <0.25 | 0.25-<0.30 | 0.30-<0.40 | 0.40~<0.60 | 0.60-<1.0 | 1.0-<1.6 | 21.6 | 0.5-<1.0 | 1.0-<1.6 | |||
| SPCC | - | 270 | 25 | 28 | 31 | 34 | 36 | 37 | 38 | - | - |
| SPCD | 240 | 270 | 27 | 30 | 33 | 36 | 38 | 39 | 40 | - | - |
| SPCE | 220 | 270 | 29 | 32 | 35 | 38 | 40 | 41 | 42 | - | - |
| SPCF (SPCEN) |
210 | 270 | - | - | 37 | 40 | 42 | 43 | 44 | - | - |
| SPCG | 190 | 270 | - | - | - | 42 | 44 | 45 | 46 | 1.4 | - |
3.Available range of GNEE Cold-rolled steel sheet for drawing series
| Item | Nominal size(mm) | |
| Thickness | 0.25-3.5 | |
| Width | 800-1830 | |
| Length | Steel plate | 1000-6000 |
| Steel strip | Coil inside diameter:508,610 | |
As a leading supplier of cold-rolled steel coils, GNEE is committed to helping clients select the exact grade and finish that best suit their needs.Contact us now to learn more about our products and services.
